| Display Specifications |
| Specification |
Details |
| Size |
65 inches |
| Dimensions (Bare Machine) |
1492.7 x 87.2 x 925.2 mm |
| Packaging Dimensions |
1660 (W) x 220 (D) x 1045 (H) mm |
| Display Area |
1428.48 mm (H) x 803.52 mm (V) |
| Pixel Pitch |
0.124 x 0.372 mm |
| Best Resolution |
3840 (H) x 2160 (V) (UHD) |
| Brightness |
350 cd/㎡ |
| Contrast Ratio |
1200:1 (Typ.) |
| Viewing Angle |
178° Horizontal, 178° Vertical |
| Response Time |
8 ms |
| Display Colors |
8 bit / 16.7 Million |
| Backlight Type |
DLED |
| Screen Lifespan |
≥50,000 hours |
| Speakers |
2 x 8Ω 15W |
| Power Consumption |
≤190W |
| Operating Voltage |
100V-240VAC, 50/60Hz |
| Net Weight / Gross Weight |
40 kg / 51 kg |
| Touch Specifications |
| Specification |
Details |
| Touch Integration |
Infrared built-in, integrated (non-external) |
| Writing Methods |
Finger, touch pen, or any non-transparent object with a diameter ≥ 5 mm |
| Touch Points |
Android 20 points, Windows 20 points |
| Touch Accuracy |
Center area < 1mm, edge area < 3mm |
| Touch Height |
2 mm |
| Response Speed |
< 10 ms |
| Touch Resolution |
32768 x 32768 |
| Touch Life Cycle |
Theoretical unlimited touches |
| Transmission Speed |
480 Mbps |
| Scan Frequency |
>100 Hz/S |
| Interface Type |
A-type USB male + UART |
| Driver |
System auto-recognition, no driver required |
| Supported OS |
Windows 7/10/11, Android, Mac OS, Linux |
| Operating Voltage |
DC 5V |
| Operating Current |
≤300mA |
| Operating Temperature |
-10℃ ~ 50℃ |
| Android Mainboard Specifications |
| Specification |
Details |
| CPU |
A55 x4, 1.9 GHz |
| GPU |
Mali-G52 MP2 (2EE) |
| RAM |
4 GB |
| Memory |
32 GB |
| System Version |
Android 11.0 |
| Front Ports |
3 x USB 3.0 (Public), 1 x HDMI IN, 1 x TOUCH USB-B, 1 x TYPE-C (Full-function 15W), 1 x Light Sensor, 1 x Remote Receiver |
| Rear Side Ports |
2 x HDMI IN, 1 x TOUCH USB-B, 1 x Android USB 2.0, 1 x Public USB 3.0, 1 x TF CARD |
| Rear Bottom Ports |
1 x COAX OUT, 1 x RS232, 1 x MINI AV IN, 1 x MINI AV OUT, 1 x EARPHONE, 1 x MIC IN, 1 x RJ45 IN, 1 x RJ45 OUT |
| Wireless Connectivity |
2.4G (WiFi) + 5G (Hotspot) + BT 5.0 |
| Buttons |
Single button: Three-in-one for screen off, OPS on/off, and system on/off |
| Audio Formats Supported |
MPEG1/2 layer I/II, AAC-Lc, WMA, etc. |
| Video Formats Supported |
MPEG-2/4, AVS, H.264, H.265, TS, Realmedia, etc. |
| Image Formats Supported |
JPG, BMP, PNG, etc. |
| Built-in Camera & Microphone Specifications |
| Specification |
Details |
| Camera Pixel |
8 MP |
| Focus Type |
Fixed focus |
| Field of View |
72.9° |
| Microphone Quantity |
Six-array omnidirectional microphones |
| Pickup Distance |
10 meters |
| Other Features |
Echo cancellation support |
