70m HDBT input board FT-4IBMUS

The FT-4IBMUS is a 4-channel HDBT input card with RJ45 interfaces, supporting 1080p60Hz resolution and up to 70-meter uncompressed transmission via Cat5e/6 cables. It features seamless switching, POC power supply compatibility, and bi-directional infrared/RS232 control, adhering to HDMI1.4b, HDCP, and HDBASET standards.
Categories:
Get Quote
Category Tags , , , ,
Description
  1. FT-4IBMUS is an HDBT network port input card with 4 RJ45 interfaces and a transmission distance of up to 70 meters. The highly integrated board-type design allows the number of boards to be selected as needed, which brings great convenience to application and maintenanc
  2. Supports seamless input of 4-way high-definition RJ45 interfaces and synchronous transmission of high-definition audio and video
  3. Supports high-definition input resolution up to 1080P@60HZ
  4. Supports HDCP protocol, HDBASET protocol, and HDMI1.4b standard
  5. Supports DVI/HDMI signal adaptation
  6. Network cable transmission supports up to 70 meters, no delay, and no compression transmission (standard super 5-level network cable)
  7. Supports remote POC power supply, and the host needs to purchase POC power supply
  8. Supports hot plugging, plug and play, and is extremely convenient. 9.Supports two-way infrared and two-way RS232 transparent control
Parameter
Interface high-speed RJ45 socket
Pixel bandwidth 165MHz, all digital
Interface bandwidth 2.25Gbps, all digital (6.75Gbps in total, 2.25Gbps for each color)
Maximum supported resolution HDPC: 1920x1200P@60_24bit; HDTV: 1920x1080P@60_36bit
Signal type high-speed differential signal
Power supply via network cable with POE power supply. For our company's CAT5 series transmitters that require POE power supply, this card input port can provide power to them through the network cable. Note that this card cannot be connected to non-our company's transmitting equipment with POE power supply
Impedance 50Ω
Maximum DC bias error 15mV
Transmission distance maximum 70 meters, at 1920x1080p@60 (recommended to use NEXANS CAT5e/6 dedicated wire)
Product weight about 0.8KG
Maximum power consumption 27W
Donwload
FT-4IBMUS
