| Technical Specifications: |
| Specification |
Value |
| Screen Size |
86" |
| Device Dimensions |
1961.1 x 87.4 x 1189.2 mm |
| Packaging Dimensions |
2157 (W) x 223 (D) x 1331 (H) mm |
| Display Area |
1895.04mm (H) x 1065.96mm (V) |
| Pixel Pitch |
0.1645 x 0.4935 mm |
| Optimal Resolution |
3840 x 2160 (UHD) |
| Brightness |
350 cd/m² |
| Contrast Ratio |
1200:1 (Typ.) |
| Viewing Angle |
178°, 178° |
| Response Time |
8 ms |
| Display Colors |
8 bit / 16.7 Million |
| Backlight Source |
DLED |
| Screen Lifespan |
≥50,000 hours |
| Speakers |
2 x 8Ω 15W |
| Power Consumption |
≤410W |
| Operating Voltage |
100V-240VAC, 50/60Hz |
| Net Weight / Gross Weight |
68 kg / 80 kg |
| Touch Specifications: |
| Specification |
Value |
| Touch Integration |
Built-in infrared, non-external |
| Writing Method |
Finger, stylus, or any non-transparent object ≥5mm |
| Touch Points |
20 points (Android), 20 points (Windows) |
| Touch Accuracy |
Center: <1 mm, Edge: <3 mm |
| Touch Height |
2 mm |
| Response Speed |
<10 ms |
| Touch Resolution |
32768 x 32768 |
| Touch Lifespan |
Theoretical unlimited |
| Transmission Speed |
480 Mbps |
| Scanning Frequency |
>100Hz/S |
| Interface Type |
USB-A male + UART |
| Driver |
Auto-recognition, no driver needed |
| Supported OS |
Windows 7/10/11, Android, Mac OS, Linux |
| Operating Voltage |
DC 5V |
| Operating Current |
≤300mA |
| Operating Temperature |
-10°C to 50°C |
| Android Mainboard Specifications: |
| Specification |
Value |
| CPU |
A55 x 4 @ 1.9 GHz |
| GPU |
Mali-G52 MP2 (2EE) |
| RAM |
4 GB |
| Storage |
32 GB |
| OS Version |
Android 11.0 |
| Front Ports |
3 x USB 3.0 (Public), 1 x HDMI IN, 1 x TOUCH USB-B, 1 x TYPE-C (15W), 1 x Light Sensor, 1 x Remote Control Receiver |
| Rear Ports (Side) |
2 x HDMI IN, 1 x TOUCH USB-B, 1 x Android USB 2.0, 1 x Public USB 3.0, 1 x TF CARD |
| Rear Ports (Bottom) |
1 x COAX OUT, 1 x RS232, 1 x MINI AV IN, 1 x MINI AV OUT, 1 x EARPHONE, 1 x MIC IN, 1 x RJ45 IN, 1 x RJ45 OUT |
| Wireless Connectivity |
2.4G (WiFi), 5G (Hotspot), BT5.0 |
| Buttons |
One button for screen off, OPS power on/off, and system power on/off |
| Audio Formats |
MPEG1/2 layer I/II, AAC-LC, WMA, etc. |
| Video Formats |
MPEG-2/4, AVS, H.264, H.265, TS, Realmedia, etc. |
| Image Formats |
JPG, BMP, PNG, and various formats |
| Built-in Camera & Microphone Specifications: |
| Specification |
Value |
| Camera Resolution |
8 MP |
| Focus Type |
Fixed focus |
| Viewing Angle |
72.9° |
| Microphone Count |
6-array omnidirectional microphones |
| Pickup Distance |
10 meters |
| Additional Features |
Echo cancellation |
