| Rated power (THD = 1%, continuous sine 1kHz, typical value) | 8Ω/stereo: 2×250W、4Ω/stereo: 2×425W、2Ω/stereo: 2×720W |
| Rated power (THD = 1%, continuous sine 1kHz, typical value) | 16Ω/bridge: 1×500W、8Ω/bridge: 1×850W、4Ω/bridge: 1×1440W |
| RMS output voltage (THD = 1%, 1kHz) | 44.7V |
| Input sensitivity | Selectable：35dB, 32dB, 29dB, 26dB |
| THD+N | typical value：0.01% (10% rated output power, 1kHz, 8Ω) |
| Crosstalk suppression | ≥90dB (below rated power, 20Hz-1kHz, 8Ω) |
| Frequency response | Typical value：+0dB, -0.5dB (10% rated output power, 20Hz-20kHz, 8Ω) |
| Input impedance | 20kΩ (balanced), 10kΩ (unbalanced) |
| Damping factor | Typical value：3500 (8Ω, 20Hz-200Hz) |
| Signal-to-noise ratio | ≥100dB (A-weighted, 20Hz-20kHz, 8Ω) |
| Power supply requirements | 90∽260VAC, 50/60Hz |
| Protection function | power supply undervoltage protection, amplifier output DC protection, overheating protection, temperature power control, overload power control |
| Dimensions | 483×45×370 (W×H×D) |
| Net weight | 9kg |
| Product static power consumption | 30 |
| Product dynamic power consumption | 116.8 |
