Amplifier FT-4A2000NA

This audio processor uses the FT-Designer platform with built-in DSP and 4-channel F-LAN network sound for flexible configuration and dual backup support. It offers 4x2000W output power, 48kHz/24bit sampling, and a comprehensive set of audio processing features like parametric equalization, dynamic processing, and monitoring. The system also includes advanced cooling, protection circuits, and a versatile power supply.
Categories:
Get Quote
Category Tags , , , ,
Description
  • Adopt FT-Designer digital network audio processing platform for configuration, debugging, monitoring and other functions. The whole series has built-in DSP and 4-way F-LAN network sound, which can be connected with other products in MBP series for network configuration. Support free and flexible debugging mode, the whole series of products support dual backup of network line, analog and network dual backup
  • Advanced Class D output line
  • Advanced switch mode power supply
  • Temperature controlled continuous variable speed fan cooling
  • Comprehensive protection circuit (thermal protection, clipping limiter, short circuit protection, etc.)
  • Embedded step attenuator
  • Support network line dual backup function
  • Support DSP function
  • Support 4-way analog sound input, 4-way F-LAN network sound input
  • Support dual backup of analog sound and network sound, and support mixing of two-way sound
  • Support 48kHz/24bit sampling rate
  • Each sound channel supports level meter display, gain adjustment (-60~12dB), mute, parametric equalization and other functions
  • Each output supports dynamic processor, frequency division, phase, delay and other functions
  • Support monitoring function, FT-Designer supports voltage, temperature, current and other data monitoring functions
Parameter
Maximum output power (EIAJ test standard) stereo 4*2000W
Working voltage 90V-264V, 50-60Hz
Input sensitivity 0.775V\1V\1.44V (switch selection)
Frequency response 20Hz-20kHz (±0.5dB)@1W,8Ω
Signal-to-noise ratio >110dB (20Hz-20kHz, A weighted)
Crosstalk isolation -80dB@1kHz
THD＋N < 0.08% from 0.1W to 1/2 power(Typically <0.05%)
DIM100 < 0.2% from 0.1W to 1/2 power(Typically <0.05%)
Input impedance 4.5kΩ Balanced
Conversion rate 50V/μs@8Ω, Input filter bypassed
Damping coefficient >500@1KHz
Dimensions (L*H*W) 483mm*88mm*290mm (2U)
Static power consumption 410
Dynamic power consumption 4500
Donwload
FT-4A2000NA
