| Rated power (THD = 1%, continuous sine 1kHz, typical value) | 8Ω/stereo: 4×1000W、4Ω/stereo: 4×1700W、2Ω/stereo: 4×2890W |
| Rated power (THD = 1%, continuous sine 1kHz, typical value) | 16Ω/bridge: 2×2000W、8Ω/bridge: 2×3400W、4Ω/bridge: 2×5780W |
| RMS output voltage (THD = 1%, 1kHz) | 89.4V |
| Input sensitivity (rated output power, 1kHz) | Optional：38dB, 35dB, 32dB, 29dB |
| THD+N | typical value： 0.01% (10% rated output power, 1kHz, 8Ω) |
| Crosstalk suppression | ≥90dB (lower than rated power, 20Hz-1kHz, 8 Ω) |
| Frequency response | Typical value：+0dB, -0.5dB (10% rated output power, 20Hz-20kHz, 8Ω) |
| Input impedance | 20kΩ (balanced), 10kΩ (unbalanced) |
| Damping factor | Typical value： 3500 (8Ω, 20Hz-200Hz) |
| Signal-to-noise ratio | ≥105dB (A-weighted, 20Hz-20kHz, 8Ω) |
| Power supply requirements | 90∽260VAC, 50/60Hz |
| Protection function | power supply undervoltage protection, amplifier output DC protection, overheating protection, temperature power control, overload power control |
| Dimensions (W×H×D) | 483×45×370 |
| Net weight | 9kg |
| Product static power consumption | 100 |
| Product dynamic power consumption | 794.4 |
