| Rated power (THD = 1%, continuous sine 1kHz, typical value) | 8Ω/stereo: 4×650W、4Ω/stereo: 4×1100W、2Ω/stereo: 4×1870W |
| Rated power (THD = 1%, continuous sine 1kHz, typical value) | 16Ω/bridge: 2×1300W、8Ω/bridge: 2×2200W、4Ω/bridge: 2×3740W |
| RMS output voltage (THD = 1%, 1kHz) | 72.1V |
| Input sensitivity | Optional：38dB, 35dB, 32dB, 29dB |
| THD+N | typical value：0.01% (10% rated output power, 1kHz, 8Ω) |
| Crosstalk suppression | ≥90dB (below rated power, 20Hz-1kHz, 8Ω) |
| Frequency response | Typical value： +0dB, -0.5dB (10% rated output power, 20Hz-20kHz, 8Ω) |
| Input impedance | 20kΩ (balanced), 10kΩ (unbalanced) |
| Damping factor | Typical value： 3500 (8Ω, 20Hz-200Hz) |
| Signal-to-noise ratio | ≥105dB (A-weighted, 20Hz-20kHz, 8Ω) |
| Power requirements | 90∽260VAC, 50/60Hz |
| Protection functions | power undervoltage protection, amplifier output DC protection, overheating protection, temperature power control, overload power control |
| Dimensions | 483×45×370 (W×H×D) |
| Net weight | 9kg |
| Static power consumption | 80 |
| Dynamic power consumption | 531.4 |
