Analog conference unit F5 S

This microphone features FionTu’s DMA digital microphone array technology with 21 microphones for excellent sound quality and long-range pickup. It allows flexible configuration as chairman units, has an electric control flip for easy operation, and integrates with conference control software. The system supports hot plug functionality and automatic repair for reliable performance.
Categories:
Get Quote
Category Tags , , , ,
Description
  • Gooseneck-free design, using FionTu's original DMA digital microphone array technology
  • Built-in 21 microphone heads, broadband pickup, long pickup distance, good directivity, excellent sound quality
  • Any unit can be flexibly configured as a chairman unit or an executive chairman unit, and there is no limit on the number of chairman units
  • Touch-type speaking switch, sensitive and convenient
  • The shell adopts one-piece molding and CNC machine tool precision processing technology
  • Embedded installation, electric control flip, easy operation, neat and beautiful desktop
  • The system has automatic repair function and supports hot plug of lines
  • According to the conference control software purchased by the user, a variety of conference management functions can be realized
    • Parameter
    Pickup technology Array microphone pickup
    Number of microphone heads 21
    Frequency response  30Hz-18kHz
    Signal-to-noise ratio >80 dB
    Dynamic range >95dB
    Total harmonic distortion <0.05%
    Power consumption 1W/10W (when flipped)
    Color Black, Silver
    Weight 3.56kg
    Microphone connection method FionTu conference six-core dedicated connection cable
    Material Aluminum alloy + sheet metal
    Electric control power supply AC85-265V 50Hz
    Dimensions (mm) length * width * height 368*90*141.5 (whole machine closed state)
    Microphone parameters
    Pickup microphone head 9.7mm diameter gold-plated capacitor type
    Directional characteristics Directional broadband type
    Sensitivity -38 dB
    Frequency response 20Hz-20KHz
    Input impedance 2.2KΩ
    Maximum sound pressure level 110 dB (THD<3%)
