Digital and analog dual backup conference unit G20 MD

This conference microphone system features a dual backup design for high reliability, with a phantom powered microphone and hand-in-hand conference system. It offers customizable chairman unit configurations, automatic camera tracking via video switchers, and an ergonomic, modern design made from zinc/aluminum alloy. The microphone is equipped with a gold-plated condenser capsule and supercardioid directionality for clear, high-quality sound.
Categories:
Get Quote
Category Tags , , , ,
Description
  • Adopting the dual backup design concept, it has a hand-in-hand conference system and a phantom powered microphone dual system. The two links work independently to ensure the high reliability of the system
  • Built-in high-performance CPU, faster processing speed and better sound quality
  • Customized chairman unit configuration function, you can temporarily define any unit as a chairman unit according to the needs of the site, and there is no limit on the number of chairman units
  • With the video switcher and camera, the camera can be automatically tracked after using the computer preset
  • The microphone can be adjusted from -50° to 45° (horizontal)
  • Exquisite and elegant tabletop structure, ergonomic, very modern
  • Made of zinc/aluminum alloy, anodized process, CNC precision processing high gloss edge, novel appearance, mainly used in high-end conferences and other professional occasions
    • Parameter
    Output frequency response 40Hz-16KHz
    Signal-to-noise ratio >74 dB
    Dynamic range >108 dB(1 KHz)
    Total harmonic distortion  <0.05%
    Maximum power consumption 1.8W
    Phantom power 48V DC
    Headphone volume 10mW
    Headphone load >16 Ω
    Headphone output interface  Ø 3.5 mm stereo jack
    Shell material Zinc/aluminum alloy
    Weight 1kg
    Color Qiang blue
    Connection method FionTu conference six-core dedicated connection cable Audio cable-2 core with shielding
    Dimensions (mm) length*width*height Microphone rod:200*34.5*23, base:138*98*54
    Microphone parameters
    Pickup microphone 14mm diameter gold-plated capacitor microphone * 2
    Directional characteristics Supercardioid
    Sensitivity -28 dB
    Frequency response 30Hz-18KHz
    Input impedance  2.2KΩ
    Maximum sound pressure level 130 dB (THD<3%)
    Equivalent noise 25 dB-A
    Donwload
    G20 MD
