FT-CE-BDY07A

The FT-CE-BDY07A is a 7-inch touch screen control device powered by the RK3399 platform and running on Android 10, suitable for smart homes and automation systems. It features a high-resolution 1024×600 pixel IPS display, supports both POE and 12V power supply, and allows for wall installation. This centralized control system is designed for use in command centers, office automation, and multimedia environments.
Categories:
Get Quote
Category Tags , , , ,
Description

FT-CE-BDY10A adopts the industry-leading RK3399 platform, supports Android 10 system, and can be used with the environmental control host. It can be applied to command and control centers, office automation, multimedia environments and smart homes. It is a fully networked and intelligent centralized control system that integrates programmable configuration protocols and programmable human-machine interfaces.

1.65K true color TFT LCD IPS display, touch screen resolution 1024×600 pixels;
2. The touch screen size is 10.0〞, and the viewing angle is 178°;
3. Support POE power supply or 12V power supply;
4. Adopts Android 10 system, RAM1G+ROM8G;
5. Supports wall installation (86 bottom box).
Parameter
CPU A133 4 cores MAX1.8GHz
Operating system Android 10
Screen size 10 LCD screen, resolution 1024*600
Touch points 10 touch points
Power supply POE or DC 12V
USB 1 USB3.0 1 USB2.0 1 Tpye-C
Power consumption 20 watts maximum
Working environment temperature 5C to 45C
9.Working environment relative humidity: 10% to 90%
VESA installation 75mm*75mm
Dimensions 260 (L) *178 (W) *41.8 mm (H)
