| Feature | Specification |
| Chassis | Standard 1U chassis |
| Control Interface | LCD panel and functional shortcut buttons |
| Video Input | 1 HDMI, 2 DVI, 1 SDI |
| Maximum Video Input Resolution | 1920× 1200@60Hz |
| Ethernet Outputs | 6 Gigabit ports, single-unit or dual-unit redundancy backup |
| Maximum Loading Capacity | 3.9 million pixels, maximum width: 8192 pixels, maximum height: 4096 pixels |
| USB Interfaces | Dual USB 2.0 high-speed communication interfaces |
| Brightness and Color Temperature Adjustment | Supported |
| Picture Adjustment | Contrast, saturation, hue, brightness compensation |
| Multi-Picture Display | 3-picture display, adjustable position and size |
| Audio Input | 3.5mm audio input, HDMI audio parsing (optional multifunctional card required for output) |
| Video Signal Processing | Arbitrary cropping, switching, scaling |
| Scene Presets | 16 presets for saving and recall |
| Color Range Conversion | "Limited to Full" (16~235) |
| Control Protocol | RS232 serial protocol control |
| Low-Brightness | Ensures complete grayscale display at low brightness levels |
