Paperless lift FT-156DNE

This product features a 15.6-inch ultra-thin capacitive LCD display with a resolution of 1920x1080, seamlessly integrated with an automatic microphone lift, ensuring a clean and elegant design. The all-aluminum construction enhances durability while minimizing noise during operation, and the device supports HDMI and VGA inputs with central control capabilities. Additionally, it includes a secondary non-touch screen of 10.1 inches for enhanced functionality.
Categories:
Get Quote
Category Tags , , , ,
Description
  • The touch ultra-thin high-definition display screen is integrated with the lifter, with no exposed connection wires, no connection backplane, and no exposed screws, ensuring that the lifting display touch screen is beautiful and generous overall
  • With integrated lift with microphone, the microphone lift has an automatic straightening function. When the microphone stem is bent, the machine can automatically straighten the microphone stem when it is turned off, without damaging the stem
  • The equipment adopts an all-aluminum structure, high-quality aluminum materials plus CNC precision carving processing, the display screen frame and chassis are made of aluminum alloy, making the overall equipment exquisite, light, beautiful and atmospheric
  • The surface treatment of the equipment is anodized, and the color is bright
  • The thickness of the equipment panel is only 3mm, the width is only 70mm, and the space occupied is small
  • The transmission structure is specially treated to minimize the noise. The central control protocol is highly compatible and compatible with all control hosts. After the control device rises, the screen automatically powers on, and after descending, the screen automatically powers off, saving and environmental protection
  • Paperless ultra-thin capacitive LCD screen lifter, with a resolution of 1920*1080P, rear electronic table card, integrated double-sided LCD display The display effect is clear and bright, and the backlight design can be adjusted to prevent fatigue caused by excessive brightness or darkness.
  • Supports HDMI and VGA two-way signal input. When only one signal is input, the screen will automatically recognize the signal. When two signals are input at the same time, they can be manually switched through the panel buttons. When there is no signal input, the screen automatically enters power saving mode.
  • The equipment can be centrally controlled through the central control software and can be controlled by the host. One button can make all the equipment in the room rise or fall.
  • The desktop panel has a USB interface, and files can be browsed or uploaded by connecting a USB flash drive
    • Parameter
    Touch screen support touch
    Lifting time 28S
    Elevation angle 0-30°, fully in line with ergonomic principles, without blocking sight and face
    Environmental conditions -20℃～50℃, relative humidity ≤70%
    Screen size 15.6
    Screen ratio 16:9
    Screen resolution 1920*1080
    Video interface 1 VGA, 1 HDMI
    Control interface 2 groups of 232/485 input and output interfaces, respectively controlling the microphone and display lifting, supporting hand-in-hand connection 1 USB port for power on/off, 1 USB port for data transmission
    Microphone connection method FionTu conference six-core dedicated connection cable
    Microphone rod length 409mm
    Backlight type WLED, 15K hours, including LED driver
    Contrast 600:1
    Brightness 300cd/㎡
    Viewing angle 45/45/20/40 (Typ.)
    Display thickness 7.65mm
    Power supply AC220V50-60/HZ
    Power consumption 25W
    Net weight 13.3KG
    Gross weight 15.56KG
    Panel size 555*70*3MM (length × width × height)
    Panel opening 556*71*3MM (length × width × height)
    Chassis size 538.2*59*647 MM (length × width × height)
    Chassis opening 540.2*61 MM (length × width)
    Secondary screen parameters
    Secondary screen size 10.1 inches
    Secondary screen does not support touch
    Secondary screen resolution 1280*800 (10.1 inches)
    Secondary screen contrast 600:1
    Secondary screen brightness 330 (10.1 inches)
    Secondary screen working environment Working temperature:0~50℃；Storage temperature: -20~60℃
    Secondary screen viewing angle 89/89/89/89 (Typ.) (CR≥10)
    Secondary screen signal system LVDS

    Microphone
    Frequency response 80Hz-16KHz
    Microphone input impedance 1KΩ
    Sensitivity -46dBV/Pa
    Maximum SPL 125dB (A)
    Signal-to-noise ratio ＞80dB
    THD ＜ 0.1%
    Power consumption 3W
