Pure power amplifier FT-B2836W

This amplifier delivers 650W output with five independently adjustable zones, Bluetooth 5.0, and supports lossless music via USB. It includes FM radio, signal mute capabilities, and advanced protection against short circuits and overheating. Ideal for medium to small public venues, it offers comprehensive control over volume, bass, and treble.
Categories:
Get Quote
Category Tags , , , ,
Description
  • High-grade aluminum 2U black oxidized brushed panel, beautiful and elegant
  • Double-sided PCB board process, stronger component adhesion and more stable performance
  • Adopting a new pure copper transformer, more powerful power and higher efficiency
  • Equipped with RCA jack, XLR jack, more flexible interface
  • Equipped with 100V, 70V constant voltage output and 4~16Ω constant resistance output
  • Adjustable output volume
  • 5-unit LED display, easy to observe the working status
  • With perfect output short circuit, high temperature, overload, DC protection function
  • Cooling fan temperature control start
Parameter
Rated output power 360W
Output mode 4-16 ohms(Ω) constant resistance output 70V(13.6 ohms(Ω)) 100V(27.8 ohms(Ω)) constant voltage output
Line input 10k ohms(Ω) < 1V, unbalanced
Line output 10k ohms(Ω) 0.775V (0 dB), unbalanced
Frequency response 60 Hz ~ 15k Hz (± 3 dB)
Non-linear distortion THD <0.5% at 1kHz, 1/3 rated output power
Signal-to-noise ratio S/N >70 dB
Damping coefficient 200
Voltage rise rate 15V/uS
Output adjustment rate < 3 dB, from no-signal static working state to full-load working state
Function control one volume adjustment, one power switch
Cooling method DC 12V FAN forced air cooling method
Indicator light power:‘POWER’, top elimination:‘CLIP’, signal:‘SINGNAL’, protection:‘PROT’, high temperature:‘TEMP’
Protection AC FUSE×10A AC FUSE×1, load short circuit, over temperature
Power cord (3×1.5 mm2)×1.5M (standard)
Power supply AC 220V ±10% 50-60Hz
Power consumption 485W
Machine size 89(H)×483(W)×366(D)mm
Donwload
FT-B2836W
