| Voltage and current | DC5.0~7.0V, 97mA |
| Network port | RJ45, 10/100Mbps, cross-connection and direct connection adaptive |
| Number of serial ports | RS485*1 (3P terminal) |
| Serial port baud rate | 600-230.4k(bps) |
| Data bits | 5, 6, 7, 8, None, 0dd, Even, Mark, Space |
| Specifications | 73.2 * 70.0 * 25.0 mm |
| Installation method | hanging ear installation |
| Working temperature | -40~85℃ |
| Working humidity | 5%~95%RH (no condensation) |
| Network protocol | IP, TCP/UDP, ARP, ICMP, IPV4, HTTP |
| IP acquisition method | static IP, DHCP |
| Domain name resolution | support, customizable DNS server address |
| Working mode | TCP Server/TCP Client/UDP Server/UDP Client/HttpClient Support ModbusRTU and ModbusTCP protocol interchange |
| TCP Server connection | supports up to 16 TCP connections (customizable) |
| Network cache | send 6Kbyte; receive 6Kbyte |
| Serial port cache | receive 1Kbyte |
| Average transmission delay | <10ms |
| Protection level | EMC level 2 |
