Speakers FT-CS60N

This speaker system utilizes F-LAN digital audio transmission for high-quality, lossless sound and is powered via PoE for energy efficiency. The built-in DSP includes 15-band EQ, gain control, and protection features like overload and short-circuit safeguards. It offers a 90°x90° coverage angle and is compact for easy installation.
Categories:
Get Quote
Category Tags , , , ,
Description
  • Adopt F-LAN digital audio transmission technology, no compression, no loss, network IP architecture, realize digital audio system
  • FT-Designer software debugging, UCI interface monitoring
  • Adopt PoE powered single-stage power conversion audio amplifier, high efficiency and energy saving and environmental protection
  • Other protection functions of power amplifier: over-current protection/over-temperature protection/overload, natural convection heat dissipation
  • Power amplifier protection function: load short-circuit protection
  • Built-in DSP processing, each speaker has 15-band EQ equalization, level meter, gain, limiter, routing, mute control and other functions
    • Parameter
    Speaker unit LF: 1x6 (1 voice coil), HF: 1x1 (1 neodymium voice coil)
    Rated power 30W (4Ω)
    Peak power 60W
    Analog input not supported
    Mixer not supported
    Effective frequency range (-10dB) 70Hz-20kHz
    Rated impedance (±20%) 4 Ω
    Characteristic sensitivity level (±2dB) 90dB/w/m
    Sound pressure level in the specified frequency band (±2dB) ≥104dB
    Total harmonic distortion ≤1%
    Coverage angle (horizontal/vertical) 90°x90°
    Socket 1*RJ45 interface
    Power supply PoE++/PoE+/PoE, 802.3bt compatible with 802.3at and 802.3af
    Installation method snap-on
    Box material ABS+iron
    Opening size 264mm Depth: 222mm
    Donwload
    FT-CS60N
