Wired and wireless integrated conference host KRP-FW01

This is a professional conferencing system with a 4.3-inch touch screen, advanced digital processing, and comprehensive features for both wired and wireless operations.
Categories:
Get Quote
Category Tags , , ,
Description
  • Adopting 4.3-inch color touch screen with hierarchical menu, the operation is intuitive and simple
  • Adopting digital technology as the core, built-in high-performance CPU, audio signal is processed by 32-bit high-speed floating-point DSP to present perfect sound quality
  • Supports both wired hand-in-hand and UHF wireless hand-in-hand to meet various conference usage scenarios
  • Supports 4.3-inch color screen to display the number of chairmen and representatives, the number of speakers, and the conference mode in wired mode; the communication channel, the number of speakers, and the conference mode in wireless mode
  • Supports one-click shutdown of all wireless microphone units, eliminating the operation of manually shutting down the power of the unit
  • Supports date and time synchronization display; with USB recording function, it can record and save the ongoing meeting with one click
  • Powered by high-performance switching power supply, long-distance transmission will not affect the sound quality
  • Built-in system settings: automatic addressing, volume setting, number of speakers, conference mode, language setting, limited time speech
  • Wired conference mode: full-open mode, chairman-only, first-in-first-out, last-in-first-out, restricted mode Number of wired speakers: In addition to the full-open mode, 1-12 people can be set to speak at the same time
  • Wireless conference mode: first-in-first-out, chairman priority, restricted mode, last-in-first-out. Number of wireless speakers: 1-4 people can be set according to actual meeting needs
  • Support time-limited speaking settings, and the microphone can be set to shut down within 3 minutes
  • Support volume settings, and the audio volume of linear input, linear output, XLR balanced output, and unbalanced output can be set
  • Support Chinese and English language settings
  • Support wired and wireless re-addressing functions, wired can add new units, and wireless can address 20 groups of channels
  • The wireless system presets 20 groups of different frequency band channels, and multiple systems can be set in the same meeting It can be used in large-scale conferences and avoid mutual interference with other wireless products
  • True diversity chip is used to enhance the wireless distance and stability of wireless transmission, and adapt to various special venue environments
  • Wireless external suction cup antenna can be adsorbed on the top of the cabinet for easy installation
  • The wireless system supports 168 microphone units; the wired system supports 4 microphone input interfaces, each supporting 30 units, and an external extender can be added to connect more units
    • Parameter
     Frequency response  20Hz-20KHz  Signal-to-noise ratio  >96dB
     Total harmonic distortion  <0.05%  Carrier frequency band  UHF640MHz-690MHz
     Modulation mode  FM  Wireless working effective distance  60 meters
     Receiving sensitivity  -95dBm  Bandwidth  30MHz
     Maximum deviation  ±45KHz  Comprehensive frequency response  45Hz-18KHz
     Central control interface  1 CONTROL (RS232) interface  Installation method  19-inch standard cabinet
     Dimensions (L×W×H)  483×323×90mm  Power supply  AC220V 50/60Hz
     Wireless antenna interface  2 1 UHF pickup antenna and 1 433 control antenna
     Other interfaces  1 LINE Lotus audio input and output, 1 TEL telephone Lotus audio input and output
     Wired input interface  4 RJ45 network ports and 4 8-core interfaces
     Audio output interface  1 XLR balanced and 1 6.35 unbalanced
     USB interface  1 USB interface, connected to PC software debugging
     Control interface  2 RS232 interfaces, 1 RS485 interface, 1 VIDEO SWITCH interface
